Build, verify and optimize the cell libraries your chips are made of

Every digital chip is built from thousands of small building blocks: logic gates, flip-flops, IO cells and memories. Our tools measure each block with SPICE, write tested Liberty, Verilog and VITAL libraries, catch library errors, and make cells faster and lower power.

  • Standard cells, IO and memories
  • Works with your SPICE simulator
  • Direct engineer support
dff_clr.acdl
*header D Flip-Flop with Clear
Q = !RB ? 0 : rising(C) ? D : "p"
$ makelib libertylibrary[SpiceTest] functional test ........ dff_clr   PASS[StateGen ] state dependency ....... dff_clr   done[StimGen  ] stimuli ................ dff_clr   done[LibChar  ] characterize NLDM, CCS . dff_clr   done[SynGen   ] Liberty model .......... dff_clr   done[SynTest  ] model vs ACDL .......... dff_clr   PASSlibrary ready: tested and verified
Illustrative run, output simplified.

What we do

From a cell description to libraries you can trust

Design tools can only build a chip correctly if they know exactly how fast every building block is, how much power it uses and how it behaves. That information lives in library files. LTI's tools create those files automatically, check them, and improve the cells behind them.

  1. 1

    Describe

    Write the function of each cell in one line of ACDL and add its SPICE netlist.

    ACDL · SPICE netlist
  2. 2

    Characterize and verify

    Measure timing and power with SPICE, generate the models and test them against the circuit.

    SolutionWare · CCSTEST
  3. 3

    Optimize and analyze

    Resize transistors for power and speed, check process variation, simulate power.

    CellOpt · ChipTimer · YieldOpt · PowerTeam
  4. ✓

    Result

    Tested Liberty, Verilog and VITAL libraries, ready for synthesis and timing analysis.

    NLDM · CCS · ECSM · CCS-Power
